HZBB-10A Transformer Turns Ratio Measuring Instrument
HZBB-10A Transformer Turns Ratio Measuring Instrument
Overview
In the production process of power transformer semi-finished and finished products, as well as before newly installed transformers are put into operation and in accordance with the preventive testing regulations of China's Ministry of Electric Power, turn ratio or voltage ratio tests must be performed on transformers. These tests verify the correctness of the transformer's turn ratio, check the condition of the tap changer, detect any inter-turn short circuits, and confirm whether the transformer is suitable for parallel operation.
Traditional ratio bridges have drawbacks such as non-intuitive readings that require conversion, and they can only measure phase by phase. The HZBB-10A Transformer Ratio Tester overcomes these limitations with user-friendly operation, intuitive display, a three-phase precision inverter power supply, fast testing speed, and high accuracy.
Technical Parameter
| Parameter | Specification |
| Test Range | Variable Ratio: 0.9 to 10000 |
| Angle: 0 to 360° | |
| Ratio Accuracy | ±0.1% + 2 digits (0.9–500) |
| ±0.2% + 2 digits (501–2000) | |
| ±0.5% + 2 digits (2001–10000) | |
| Angle Accuracy | ±0.2° |
| Output Voltage | Automatically adjusted according to load |
| Resolution | Ratio: Minimum 0.0001 |
| Angle: 0.01° | |
| Working Power Supply | AC 220V ±10%, 50 ±1Hz |
| Environmental Temperature | -10℃ ~ 40℃ |
| Relative Humidity | ≤85%, no condensation |
| External Dimensions | Host: 360×290×170 mm |
| Cable Box: 360×290×170 mm | |
| Weight | Main Unit: 5 kg |
| Box: 5.6 kg | |
| Test Line Length | Standard 13 m, customizable |
Storage And After-Sales Service
1 The instrument and its supporting facilities should be stored indoors, the ambient temperature is 0 ° C ~ 40 ° C, the relative humidity is 30% ~ 80%, and the air should not contain harmful substances that cause corrosion.
2 Instrument from the date of purchase within one year, belongs to the company's product quality problems free maintenance, lifetime warranty and technical services. If you find that the instrument is abnormal or faulty, please contact the company in time to arrange the most convenient solution for you and provide you with the fastest on-site service.
Packing List
|
No. |
Item |
Qty |
|
1 |
Host machine |
1 |
|
2 |
Test line |
1 |
|
3 |
Power cable |
1 |
|
4 |
Operation manual |
1 |
|
5 |
Quality certificate |
1 |
|
6 |
Fuse tube |
2 |
|
7 |
Printing paper |
1 |
|
8 |
Packing list |
1 |
|
9 |
Ground line |
1 |
|
10 |
Communication cable |
1 |
