HZNQ-1102 ASTM D2500 Cloud And Pour Point Test Kit
Huazheng Electric Manufacturing (Baoding) Co., Ltd. is one of the leading manufacturers and suppliers of hznq-1102 astm d2500 cloud and pour point test kit in China. Please feel free to buy high quality equipment for sale here from our factory. Good service and reasonable price are available.
HZNQ-1102 ASTM D2500 Cloud And Pour Point Test Kit
I. Product Overview
This instrument is designed and manufactured in accordance with the provisions of several key standards: the People's Republic of China standards GB/T 510 Petroleum Products – Determination of Freezing Point and GB/T 3535 Petroleum Products – Determination of Pour Point, as well as ASTM D2500. The design is further tailored to meet specific user requirements.
The instrument incorporates a new type of compressor, an advanced digital temperature controller, and a unique refrigeration bath. This combination delivers excellent refrigeration performance, high temperature control accuracy, and a uniform, stable cold bath temperature throughout testing.
The tester is suitable for oil exploration, production, and application units, as well as related institutions and scientific research departments, for the determination of freezing point and pour point of petroleum products.
II. Technical indicators
| Item | Specification |
| Working Cold Bath | Single bath with two tanks, both isothermal |
| Cooling Bath Temperature Range | Room temperature to -70°C |
| Temperature Control Accuracy | ±0.5°C |
| Refrigeration System | New refrigeration compressor |
| Ambient Temperature | ≤30°C |
| Relative Humidity | ≤85% |
| Power Consumption | ≤700W |
| Working Power Supply | AC (220±10%)V, 50Hz |
| Dimensions | 600mm × 450mm × 340mm |
III. Working principle
In accordance with the national standard requirements for test methods such as pour point and freezing point, place the test tube containing the sample into the instrument's cold bath. Set the test temperature and counting time according to the specifications of the relevant test method. When the instrument's temperature control system reaches the preset test temperature, tilt the test tube for one minute and observe the test result.
