HZ-6300C Transformer Capacity and Loss Characteristic Tester

HZ-6300C Transformer Capacity and Loss Characteristic Tester:This test equipment comes with a high-efficiency rechargeable battery, which can work without an external power supply. It can continuously measure 500 units after a charge.

Huazheng Electric Manufacturing (Baoding) Co., Ltd. is one of the leading manufacturers and suppliers of hz-6300c transformer capacity and loss characteristic tester in China. Please feel free to buy high quality equipment for sale here from our factory. Good service and reasonable price are available.

HZ-6300C Transformer Capacity And Loss Characteristic Tester

Summary

This transformer capacity testing instrument is equipped with a high-efficiency rechargeable battery, enabling operation without an external power supply. It can perform up to 500 consecutive measurements on a single charge.

Meanwhile, it internally generates a three-phase standard sine-wave signal through digital synthesis (rather than simple inverter-based AC output), ensuring accurate test data under non-rated conditions for the following test items. Its power amplifier module provides a high-precision three-phase AC test source. When measuring transformer capacity and short-circuit loss, no auxiliary equipment-such as a three-phase test power supply, voltage regulator, or step-up transformer-is required.

HZ-6300C Transformer Capacity Characteristic Tester

Technical Data

The output range of built-in battery
Voltage	0～10V
Current	0～10A
The output range of test battery
Voltage	0～750V
Current	0～100A
Precision
Voltage, current	±0.2%
Power	±0.5%(CosΦ>0.1), ±1.0%(0.02
Volume	32×25×12

transformer capacity test set

Note

1. The connecting method of testing line should operate according to instruction, otherwise it will affect the result

2. The wiring should be proceeded when the testing line has grounded in order to electric shock of induced voltage.

3. Please ensure the voltage ,current under the testing range. It need to connect with CT PT to expand the range, or testing result will not right.

4. When instrument do capacity test, active load test, load test,

Please ensure the short circuit of the no-pressure side, otherwise it will affect the result.

5. When doing the load test, if there is the power casing of HV LV side(Eg: CT), Please ensure short circuit of secondary winding of CT.
