CT PT Analysis Instrument Current and Potential Transformer Analyzer Characteristics Comprehensive Tester
Product Introduction
The quality of our voltage divider 50kv 100kv 150kv 300kv, cable fault pinpointer, vlf high voltage generator is top-notch and our customers have always regarded our company as the most reliable one. We have developed core competencies in technological innovation, market expansion, corporate culture, and sustainable development. Our company uses a brand-new sales and publicity model to complement the fine products of Seiko. Adhering to the people-oriented principle and pursuing the principle of independent innovation, after years of hard work and development, it has become a leader in the industry. We insist on using technological innovation to create leading quality, and continuously achieve product optimization and upgrading. We manufacture high-quality products with modern business methods and brand-new marketing concepts to repay our customers for their consistent trust, support and love.
HZCT-100B Variable Frequency Automatic Current Transformer CT PT Analyzer
Instrument Characteristics And Parameters
The HZCT-100B CT PT analyzer is a new product developed following extensive customer feedback and in-depth theoretical research. It is built upon the widely acclaimed and successfully deployed FA Series Transformer Tester platform from our company. The adoption of high-performance DSP and ARM technology, combined with advanced manufacturing processes, ensures stable and reliable product performance, comprehensive functionality, a high degree of automation, and exceptional efficiency-achieving a leading position in the domestic market. These instruments serve as professional testing equipment for transformer verification in the power industry.
Technical Parameter
HZCT-100B | ||
Usage | CT, PT | |
Output | 0~180Vrms,12Arms,36A(peak value) | |
Voltage measurement accuracy | ±0.1% | |
CT Ratio | Range | 1~40000 |
Accuracy | ±0.05% | |
PT Ratio | Range | 1~40000 |
Accuracy | ±0.05% | |
Phase | Range | ±2min |
Accuracy | 0.5min | |
DC resistance | Range | 0~300Ω |
Accuracy | 0.2%±2mΩ | |
Burden | Range | 0~1000VA |
Accuracy | 0.2%±0.02VA | |
Power supply | AC220V±10%,50Hz | |
Environmental Conditions | Operating temperature : -10οC~50οC ,Humidity :≤90% | |
Weight and Dimensions | Dimensions: 365 mm×290 mm×153mm,Weight<10kg | |
Warranty
For the products manufactured by our Company, if the defects appear within 3 months from the date of delivery, we can provide the replacement; if the defects appear within one year from the data of delivery, we can provide free services and repairs; if the defects appear more than one year after delivery, we can provide life-long paid maintenance services.
Our company combines international advanced technology, constantly exploring in practice, and has always been in a leading position in CT PT Analysis Instrument Current and Potential Transformer Analyzer Characteristics Comprehensive Tester industry. Firm's core competence is one of the most influential and most important concepts in the field of business strategy management in recent years. Our company has a large inventory, complete varieties, stable supply, timely supply, won the praise of our customers.
