HZ-5100 Switch Loop Resistance Tester Contact Resistance Measurement

HZ-5100 Switch Loop Resistance Tester Contact Resistance Measurement

Contact resistance measurement data is accurate and correct, high stability and satisfy the requirements of Power, power supply department on-site high-voltage switch repair and high voltage switch factory contact resistance test.

Technical Index

Current measurement: 50A, 100A

Range : 0～100mΩ(50A) 0～50mΩ(100A)

Resolution : 0.1µΩ At Min.

Precision : ±(0.5%±2)

Instrument Operation Function

1.Power switch: Press T to supply power, press O to cut off power supply.

2.Power input terminal, adopt AC 220V power supply.

3.I+, I- :Current output terminal, supply the constant current to the tested object by special testing wire.

4. V+,V- ： Input voltage terminal for tested object.

5. LCD: 320X240 true color LCD, under the bright, font can also be clearly observed, display operation settings, test results, contact resistance value and output current value.

6. RS232: Serial port.

7. : Ground terminal.

8. USB: U disk storage connector.

9. Printer: Thermal printer, prints the testing results.
